Flat Solar Colletor 20Khz Ultrasonic Metal Continous Welding Equipment

Description:

The application of ultrasonic metal welding technology has brought about a major improvement in people's quality of life. The professional manufacture of ultrasonic metal welding equipment in Taiwan has introduced this technology into the field of solar energy, leading the overall improvement of industrial equipment manufacturing technology.

The ultrasonic Rolling welding system is mainly composed of an ultrasonic generator, a transducer, a welding head and a pneumatic part. The system is easy to install, install and operate. All important welding parameters ensure an extremely high weld quality.

Specifications:

Advantages of ultrasonic metal welding machine:

1. high welding strength;
2. non-sparking welding, environmental protection and safety;
3. near cold processing, no annealing of workpiece, no trace of oxidation;
4. good electrical conductivity after welding, extremely low or near zero resistance;
5. low requirements on welded metal surface , oxidation or electroplating can be welded;
6. welding time is short, no need for any flux, gas, solder.

Comparison between Laser welding and ultrasonic welding:

In the solar heat absorbing plate welding, welding is performed in the form of a solder joint with a spacing of 3-5 mm. Laser welding uses a high-energy laser to melt the weld metal to create a joint.

The advantage is that no pressure is required on the workpiece to be welded, the overall deformation is small, and the surface damage of the heat absorption layer is small.

However, the disadvantage is that the absolute heat conduction area between the metal piece and the copper tube is small, which affects the heat conduction efficiency; the copper tube has high flatness requirements and is not easy to be aligned with the welding position; the solder joint strength is poor, and the hot and cold alternates frequently or is subjected to external force. Solder joints are prone to breakage.

In order to further improve the thermal performance, safety and refinement of solar heat absorbing panels,using the automotive and shipbuilding industries as the reference parent, and applies ultrasonic metal technology to solar energy products, greatly improving the welding robustness of the collector. And precision. In terms of heat transfer efficiency, even if ultrasonic welding produces weld marks on the heat absorbing plate, the product of the ultrasonic welding machine is about 3% higher than the heat transfer efficiency of the laser welding (that is, the water temperature is about 3% higher under the same working condition)

Flat Solar Colletor 20Khz Ultrasonic Metal Continous Welding Equipment​

Hangzhou Qianrong Automation Equipment Co.,Ltd.

Is the professional manufacturer of ultrasonic research, high power ultrasonic transducer development and production in China.

Our main products are Ultrasonic Welding transducer, ultrasonic power supply, ultrasonic metal welder, ultrasonic wire antenna parts and so on. These productions are widely used in various fields, such as plastic welding, metal welding, non-woven sealing and cutting and so on.

Since Qianrong Equipment establishment, the company has always focused on customer needs. While exploring the domestic market in China, we also demonstrates our company’s ultrasonic technology to the world. Its quality and performance are well-known in the industry.

Adhering to the “focus on ultrasonic application, in good faith to win customers, to win the reputation of quality” development purpose, becoming the world’s leading supplier of ultrasonic core components, through our professional level and unremitting efforts, quality products for customers in the development of the industry to create greater value return.
