Ultrasonic Non Woven Rotary Welding System
Description:
Ultrasonic sewing machine core is a sewing machine core component
based on ultrasonic technology, used to achieve needle free sewing.
It is an innovative sewing technology that, compared to traditional
needle and thread sewing, does not require the use of needles and
threads. Instead, it utilizes the vibration of ultrasonic waves to
generate heat energy, laminating materials together to achieve
sewing effects.
Principle:
Ultrasonic vibration: The ultrasonic vibrator produces
high-frequency ultrasonic vibration.
Thermal energy generation: Ultrasonic vibration can cause
frictional heat between materials, causing an increase in surface
temperature of the materials.
Pressing and connecting: When the surface temperature of the
material reaches the melting point, the material is laminated
together with appropriate pressure to melt and bond together.
Parameters:
| Model | FSSW-3508-Ti |
| Name | 35Khz Ultrasonic Rotary Welding Machine
|
| Frequency | 35Khz |
| Power | 800w |
| Input Voltage | 220V±10%,50/60Hz |
| Welding Amplitude | 18-28μm |
| Materials of horn | Titanium Alloy or Special Steel |
| Application | Fabric cutting, lace cutting, clothing stitching, gluing, bead
inlay |
Features:
1. No needle or thread required: The ultrasonic sewing machine does
not require the use of traditional needles and threads, eliminating
issues related to threading, thread ends, and needle holes.
2. High speed and efficiency: Ultrasonic sewing can achieve
high-speed sewing and improve production efficiency.
3. No need for pre drilling: Ultrasonic vibration can penetrate the
material and generate heat energy on the surface in contact,
without the need for pre drilling.
4. Beautiful and firm: Ultrasonic sewing can achieve uniform sewing
effect, making sewing more beautiful and firm.
Ultrasonic sewing machine cores are widely used in fields such as
textiles, clothing, automotive interiors, and household goods,
especially in production environments that require high speed and
efficiency. It can improve production efficiency, simplify
operating procedures, and have good stitching effects.
