    High Performance Textile Flame Retardant Ultrasonic Coating Technology

    Ask Lasest Price
    Brand Name : FUNSONIC
    Model Number : FS2000-8
    Certification : CE
    Payment Terms : T/T, Western Union
    Supply Ability : 1000 unit per month
    • Product Details
    • Company Profile

    High Performance Textile Flame Retardant Ultrasonic Coating Technology

    High Performance Textile Flame Retardant Ultrasonic Coating Technology


    Description:


    High performance textile flame retardant ultrasonic coating technology is mainly applied in the field of textiles and can be used for functional coating processes of coatings and high-performance textiles. High performance textile flame retardant ultrasonic coating technology is suitable for various fabrics, such as cotton, linen, synthetic fibers and other fabrics. By using ultrasonic spraying technology, functional coatings such as waterproof, breathable, antibacterial, and flame-retardant are formed on the surface of fabrics.
    Compared with traditional immersion or immersion rolling processes, high-performance textile flame retardant ultrasonic coating technology precisely controls the deposition of coatings, forms uniform nano films, and significantly reduces the use of water, chemicals, and energy, with high environmental performance.


    Parameters:


    Product TypeIntelligent Ultrasonic Precision Coating Machine Type FS2000-8
    Spray Nozzle Operating Frequency20-200KHz (Normally use 60100110120K)
    Nozzle Power1-15W
    Continuous Spraying Volume Max0.01-50ml/min
    Effective Spraying Width2-100mm
    Spray Uniformity≥95%
    Solution Conversion Rate≥95%
    Dry Film Thickness20nm-100μm
    Solution Viscosity≤30cps
    Temperature Range1-60℃
    Atomized Particles (Median Value)10-45μm (distilled water), determined by the frequency of the nozzle
    Diversion Pressure Max≤0.15MPA
    Input Voltage220V±10%/50-60Hz
    Exercise ModeXYZ three-axis, independently programmable
    Control ModeFUNSONIC spraying control system, PLC control, 13.3-inch full-color touch screen
    Control ContentUltrasonic spraying, liquid supply, heating, ultrasonic dispersion and other systems

    Application :


    1. Firefighting suit: a clothing worn by professional firefighters to enhance safety.
    2. Industrial workwear: Suitable for workers in high-risk environments, providing additional protection.
    3. Household items: such as curtains and sofa fabrics, to increase fire safety.
